outdoor GPRS TVOC air quality monitor with GC-PID sensor for TVOC Benzene, toluene, , xylene, styrene
Description:
The system can monitor TVOC (aromatic hydrocarbons: benzene, toluene, ethylbenzene, xylene, etc.;Ketone, halogenated hydrocarbons: trichloroethylene, perchloroethylene and other 300 kinds of VOC gases) H2S,NH3,CO,NO2,O3,SO2,CL2,NO,HCL,Temperature,Humidity,Wind speed,Wind direction,Pressure and other pollutants(expandable) in the environment. The system pushes the collected data to the on-site display screen in real time for reference of on-site personnel, and upload it to the cloud platform of the system. T
Features:
- Easy for installation
- MFC technology for flow control, accurate and stable
- Cloud services on the Big Data computing
- Real-time monitoring
- Real-tie data transmission
- Imported Valco six way valve, small volume, no moving parts, low maintenance, long service life
Technical Parameters:
- Power supply: Solar (with backup battery)
- Working time: >300h (continuous working at 20℃)
- Working temperature: -30 to 60℃
- Working humidity: ＜95%RH (No condensation)
- PM sensor type: Laser sensor
- TVOC sensor type: GC-PID
- Speed/direction sensor: Mechanical sensor
Sensor data:
| Sensor | Range | Resolution | Accuracy | Ramark |
| PM2.5 | 0-1000μg/m3 | 1μg/m3 | ±10%FS | Standard |
| PM10 | 0-1000μg/m3 | 1μg/m3 | ±10%FS | Standard |
| SO2 | 0-1000μg/m3 | 1μg/m3 | ±10%FS | Standard |
| NO2 | 0-1000μg/m3 | 1μg/m3 | ±10%FS | Standard |
| CO | 0-5000μg /m3 | 1μg/m3 | ±10%FS | Standard |
| O3 | 0-1000μg/m3 | 1μg/m3 | ±10%FS | Standard |
| Temp. | -40℃-70℃ | 1℃ | ±1℃ | Standard |
| Hum. | 10-95%RH | 1%RH | ±2%RH | Standard |
| Speed | 0-30m/s | 0.1m/s | ±0.3m/s | Standard |
| Direction | 0°-360° | 1° | ±1° | Standard |
| TSP | 0-20mg/m3 | 1ug/m3 | ±10%FS | Optional |
| Noise | 30-130dB | 1dB | ±10%FS | Optional |
Application:
